Products Description

Diatomaceous Earth Filter

Diatomaceous earth filter refers to the coating filter with diatomaceous earth coating as the filtration layer, mainly using the mechanical sieving action to deal with the water filtration treatment process containing tiny suspended matters. Diatomaceous earth filters filtered wines and beverages have unchanged flavour, are non-toxic, free of suspended solids and sediments, and are clear and transparent. The diatomite filter has high filtration accuracy, which can reach 1-2 microns, can filter out Escherichia coli and algae, and the turbidity of the filtered water is 0.5 to 1 degree. The equipment covers a small area, low height of the equipment, the volume is only equivalent to 1/3 of the sand filter, can save most of the investment in civil construction of the machine room; long service life and high corrosion resistance of filter elements.

Working Principle

When the Diatomaceous Earth Filter makes the filtration, it will form into the precoating on the filter discs first. When the
liquid to be filtered go through the precoating, the impurities will be blocked and the clean pured filtered liquid will pass from the gaps among the DE to realize the purification function.

After one filtration cycle, the backwashing pump will clean the filter discs to start the next filtration better.

Structure

The core part of the diatomite filter is composed of three parts: cylinder, wedge mesh filter element and control system. Each filter element is a perforated tube that serves as a skeleton, with a filament wrapped around the outer surface, which is coated with a diatomaceous earth cover. The filter element is fixed on the partition plate, above and below which are the raw water chamber and the fresh water chamber. The entire filtration cycle is divided into three steps: membrane spreading, filtration and backwashing. The thickness of the filter membrane is generally 2-3mm and the particle size of diatomaceous earth is 1-10μm. After the filtration is finished, backwashing is often done with water or compressed air or both. The advantages of the diatomite filter are good treatment effect, small washing water (less than 1% of the production water), and small footprint (less than 10% of the ordinary sand filter area).

Specification

Company Profile

Shanghai Junyi Filter Equipment Co., Ltd. specializes in the manufacturing and sales of filter equipment. We have professional and experienced technical team, production team and sales team, provide good service before and after sales. Adhering to the modern management mode, we always make the precision manufacturing, explore new opportunity and make the innovation.
